1、节能效益,按WZ1000型计算,一年节约蒸汽3500吨,节约水9万吨,节约电8万度,折人民币10-15万元.(与同规格的单效对比)
2、本浓缩器采用二效同时蒸发，二次蒸汽得到充分利用既节省了锅炉的投资，又节约能耗，能耗与单效浓缩器相比降低50%。
3、本设备采用外加热自然循环与真空负压蒸发方式，蒸发速度快，浓缩比重大。液料在全密封中无泡沫浓缩，用本设备浓缩出来的药液，具有*，药味浓。清洗方便（打开加热器的上盖即可）
4、本设备与液料接触部位均采用（OCr18Ni9）不锈钢制成，符合GMP标准。加热器、蒸发器、外加保温，保温外层用花纹不锈钢薄板，设备在车间显得更为豪华美观。
Usage
This equipment is suitable for low temperature vacuum condensation of heat-sensitive materials such as Chinese medicine, western medicine, glucose, wine, starch, oral
solution, chemicals, foodstuffs, monosodium glutamate and dairy products. You may choose different concentrator according to different concentrating requirement.
Features and benefits
1. Energy-saving Calculated with WZ1000 type, it will save 3500 tons of vapor, 9 tons of water, 80000 KWh of electricity, equivalent to 100-150 thousand yuan(compared with
single-effect one of same specification).
2. This concentrator uses double-effect vapor, not only saving investment on boiler, but also saving energy, reducing 50% compared with single-effect concentrator.
3. This equipment uses extrinsic heating natural circulation and vacuum pressure evaporation, with fast evaporation speed and large specific density of concentration.
The fluid is concentrated without foam in totally enclosed condition. The extract from this equipment is without pollution, with thick medicinal flavor. It is easy to clean(just
open the top cover of the heater).
4. The parts in contact with fluid in this equipment are made of OCr18Ni9 stainless steel in conformity with GMP standard. The heater and evaporator are covered with heat
preservation layers with outer surface made of checkered stainless steel sheet.
|
|
型 号 Item |
DJZ500a |
DJZ1000a |
DJZ1500a |
DJZ2000a |
|
蒸发量（kg/h清水）
Evaporation capacity(clear water) |
500 |
1000 |
1500 |
2000 |
|
耗汽量 （kg/h）
Vapor consumption |
250 |
500 |
750 |
1000 |
|
外形尺寸：长×宽×高（M）
Dimensions |
4×1.3×3.5 |
5×1.6×3.5 |
5.7×1.7×4 |
6.3×1.8×4.5 |
|
循环耗水量 （T/h）
Recycling water consumption |
6 |
12 |
15 |
18 |
|
蒸发温度
Evaporation temperature |
一效 First effect |
80-90 |
真空度（MPa）
Vacuum |
一效 First effect |
0.02-0.04 |
|
二效 Second effect |
55-70 |
二效 Second effect |
0.05-0.08 |
|
蒸汽压力（MPa） Vapor pressure |
一效0.2 First effect |
浓缩比重 Concentration ratio |
1.2-1.3 |
|
容器类别
Vessel type |
一 类 First class |
| |
